Height-adjustable Comfort Handlebar
COMFORTABLE WORKING AND STORAGE. The comfort handlebar is only mounted on one side of the lawn mower, making it easier for you to remove the grass collection box. As the handlebar is height-adjustable, it enables you to mow your lawn comfortably and ergonomically. You can adjust it to your preferred height without using tools. As the handlebar is also foldable, the lawn mower can be compactly stored and transported.
Polymer Housing
HIGH-RESISTANCE AND LIGHTWEIGHT. The highly resilient and robust polymer housing is petrol-resistant and protects the engine block against UV radiation. The high-quality plastic is also exceptionally light.
Eco Mode
ENERGY-EFFICIENT WORKING. With Eco mode activated, the speed of your lawn mower engine automatically adapts to the output you actually need. This means that your cordless lawn mower uses less energy and can handle a larger area before it needs to be charged again.
Central Cut-height Adjustment
FOR OPTIMUM MOWER RESULTS. You can adjust the cutting height on your lawn mower easily and in several levels. A scale shows the current height. Central cut-height adjustment allows you to optimally adapt your mowing to the conditions of the lawn.
Smooth-running Wheels
IMPROVE CONTROL. With robust and durable smooth-running wheels, you can keep track of your lawn mowing easily and effortlessly. Thanks to their traction and directional stability, these smooth-running wheels can be effortlessly manoeuvred to support careful and comfortable lawn maintenance.
Folding Grass Collection Box
EASY EMPTYING. Your lawn mower is equipped with a folding grass collection box to make emptying clippings very straightforward. The fill-level indicator signals the right time for emptying. An airstream ensures dense filling while mowing, so you can make optimum use of the full volume of the box. The slats on the side of the box direct the air towards the ground, which protects you from dirt being swirled up.
Vario Self-drive
The Vario self-propulsion enables individual adaptation of the speed of the STIHL lawn mower to personal mowing habits and lawn conditions. The mowing speed can be infinitely varied using the control lever on the handlebar.
Power boost
MAXIMUM PERFORMANCE INCREASE. Thanks to intelligent electronics, STIHL power tools and batteries communicate with each other. If the device and battery are equipped with the POWER BOOST function, the battery always provides the maximum possible power for the respective application. In order to ensure optimum battery life, the device temporarily adjusts the power if it is used too intensively.
Constant power
CONSTANT POWER, REGARDLESS OF BATTERY CHARGE STATUS. With other brands of battery tools, the performance usually decreases during work as the battery discharges. This is not the case with STIHL cordless power tools with CONSTANT POWER. Thanks to the intelligent electronics, your STIHL power tool works with consistently high power.
Flow-optimised blades
ENERGY-EFFICIENT WORKING. Flow-optimised blades mean your lawn mower uses less electricity; as a result, you can use cordless mowers to mow larger areas with the same amount of energy, even without charging. The blades trim the grass with minimal air resistance, making optimal use of the stored energy.
Carry handle
EASY TO TRANSPORT. The practical carry handle ensures that you can carry your power tool very easily.
IPX4 Certified
SPLASHWATER PROTECTION. The IPX protection classes define the moisture protection of electrical or electronic devices. The moisture protection test is defined in different stages. IPX4 certifies protection against splashwater from all sides. Battery-powered tools with this certification are therefore designed for daily use, even in rainy conditions.
Technical details
Battery system |
AK |
Drive |
2,0 - 4,5 km/h |
Recommended battery |
AK 30 S |
Device weight without battery |
26 kg |
Cutting width |
41 cm |
Cutting height |
20 - 100 mm |
Rated speed of sweeping attachment |
3000 r/min |
IPX Rating |
IPX4 |
Max. area per battery charge AK 10 |
135 m² 1) |
Max. area per battery charge AK 20 |
270 m² 1) |
Max. area per battery charge AK 30 |
350 m² 1) |
Max. area per battery charge AK 30 S |
350 m² 1) |
Grass catcher box volume |
52 l |
Device width without attachments |
50 cm |
Max. device height |
108 cm |
Front wheel diameter |
190 mm |
Rear wheel diameter |
215 mm |
Measured sound pressure level LpA |
75 dB(A) |
Sound power level, guaranteed LWA |
90 dB(A) |
Uncertainty factor, sound pressure level KpA |
2 dB(A) 2) |
Vibration, guide bar, ahw |
1.40 m/s² |
Vibration uncertainty K |
0.70 m/s² 2) |
